CC560 MESH V2 WH
The DeepCool CC560 MESH V2 WH mid-tower case offers great value with spacious component compatibility, a full-sized tempered glass window, a fine mesh front panel, and a total of four pre-installed ARGB fans that get any build started right. The V2 model builds upon the success of the previous generation and raises the bar.
COLOR
white
MODEL
CC560 MESH V2 WH
REFINED MESH AIRFLOW CASE
SCENIC VIEW
The lack of an A pillar between the front and side tempered glass panels removes the main obstruction to a clear and uninterrupted view of your incredible build.
KEEPING IT CLEAN
The internal single chamber layout optimizes the available space with 33mm of cable management space, while the motherboard tray supports motherboards with back connectors from ASUS and MSI; as a result, your system will look more steamlined and cleaner than ever before.
THE SUPPORT
YOU NEED
Designed to support up to ATX motherboards, 360mm radiators at the top and side, 410mm long GPUs (limited to 262mm if a radiator and fan set are mounted on the side), 210mm PSUs, 176mm tall air coolers, and up to 9 120mm fans, the CG580 WH can be configured in a wide array of combinations for your modern hardware needs. The bottom position can support either a 120mm fan or a 3.5"" HDD drive.
Radiators:
Top: 120/140/240/280/360mm
Side: 120/240/360mm
Rear: 120/140mm
Fans:
Top: 3x120mm/2x140mm
Side: 3x120mm
Rear: 1x120mm/1x140mm
Bottom: 1x120mm
PSU Shroud: 2x120mm
  • ATX
  • COOLER
  • GPU
  • PSU
  • RADIATORS
  • FANS(120)
  • FANS(140)
  • HDD
QUALITY OF LIFE FEATURES
With two USB 3.0 ports and a hybrid audio port that can be accessed from the top I/O panel, connecting temporary devices is a breeze. The magnetic top filter keeps dust out of your system and makes cleaning a little easier.
Technical Spec
Product Dimensions432×215×483mm(L×W×H)
Net Weight6.2Kg
MaterialsABS+SPCC+Tempered Glass
Motherboard SupportMini-ITX / Micro-ATX / ATX
Front I/O PortsUSB3.0×2、Audio×1
3.5" Drive Bays2
2.5" Drive Bays2+1
Expansion Slots7Slots
Pre-Installed FansFront: 3×120mm ARGB
Rear: 1×120mm ARGB
Fan SupportFront: 3x120mm/3×140mm
Top: 2×120mm/2x140mm
Rear: 1×120mm
PSU Shrouded: 2×120mm
Radiator SupportFront: 120/140/240/280/360mm
Top: 120/140/240/280mm
Rear: 120mm
CPU Cooler Height Limit165mm
GPU Length Limit370mm
Power Supply TypeATX PS2（maximum length: 170mm）
EAN6933412774174
P/NR-CC560-WHAMA4-G-2
Download
CC560 MESH V2 WH Manual.pdf
